DXS-3130-28P - D-LINK 28-Port Stackable 10 Gigabit PoE++ Lay

Hardware
Networking
Stackable Switches
28-Port Stackable 10 Gigabit PoE++ Layer 3 Switch with 24 Multi-Gigabit 10G PoE++ ports and 4 25G...

All our products are Australian stock and come with a full manufacturer's warranty

Please login first.

28-Port Stackable 10 Gigabit PoE++ Layer 3 Switch with 24 Multi-Gigabit 10G PoE++ ports and 4 25G SFP28 ports. PoE budget up to 1440W.

Management & Protocols
Manageable	Yes
Reliability
MTBF	286495.20 Hour
I/O Expansions
Expansion Slot Type	SFP28
Total Number of Expansion Slots	4
Technical Information
Features	Hot-swappable
High Availability Supported	Yes
Miscellaneous
Application/Usage	Enterprise
	IP Camera
	IP Surveillance Network
	VoIP Phone
	Wireless Access Point
Physical Characteristics
Weight (Approximate)	6.48 kg
Form Factor	Rack-mountable
Height	43.9 mm
Width	439.9 mm
Depth	469.9 mm
Product Color	Black - Grey
General Information
Product Type	Ethernet Switch
Manufacturer Part Number	DXS313028P
Manufacturer Website Address	http://www.dlink.com.au
Manufacturer	D-Link Systems, Inc
Product Model	DXS-3130-28P
Product Name	DXS-3130-28P Ethernet Switch
Product Series	DXS-3130
Brand Name	D-Link
Interfaces/Ports
Network (RJ-45)	Yes
Stack Port	Yes
Total Number of Network Ports	24
Port/Expansion Slot Details	4 x 10/25 Gigabit Ethernet SFP28 Expansion Slot
	24 x 100/1/2.5/5/10BASE-T Gigabit Ethernet PoE++ RJ-45 Network Port
	1 x USB 2.0 Type A port
	1 x 10/100/1000BASE-T RJ-45 Console Port
	1 x 10/100/1000BASE-T RJ-45 Management Port

Power Description
Input Voltage	230 V AC
	120 V AC
Power Source	AC
	Power Supply
Frequency	50 Hz
	60 Hz
Power Consumption	95.90 W
Number of Power Supplies Supported	2
Number of Power Supplies Installed	2
PoE (RJ-45) Port	Yes
Redundant Power Supply Supported	Yes
PoE Budget	790 W
Media & Performance
Network Technology	2.5GBase-T
	10GBase-X
	10GBase-T
	10/100/1000Base-T
	25GBase-X
	5GBase-T
Maximum Data Transfer Rate	3.13 GB/s
Ethernet Technology	Gigabit Ethernet
	25 Gigabit Ethernet
	2.5 Gigabit Ethernet
	10 Gigabit Ethernet
	5 Gigabit Ethernet
Media Type Supported	Twisted Pair
	Optical Fiber
Network & Communication
Layer Supported	3
Networking Standards	IEEE 802.3x
	IEEE 802.3an
	IEEE 802.3at
	IEEE 802.3az
	IEEE 802.3bt
	IEEE 802.1ag
	IEEE 802.1AX
	IEEE 802.1D
	IEEE 802.1p
	IEEE 802.1Q
	IEEE 802.1s
	IEEE 802.1v
	IEEE 802.1w
	IEEE 802.1x
	IEEE 802.3
	IEEE 802.3ad
	IEEE 802.3ae
	IEEE 802.3af
	IEEE 802.3ah

D-LINK 28-Port Stackable 10 Gigabit PoE++ Layer 3 Switch with 24 Multi-Gigabit 10G PoE++ ports and 4 25G SFP28 ports. PoE budget up to 1440W.
