Apc NETSHELTER Rack PDU Advanced Switched Metered Outlet 34.6KW 3PH 415V 60A 560P6 42 Outlet

All our products are Australian stock and come with a full manufacturer's warranty

Please login first.

Apc NETSHELTER Rack PDU Advanced Switched Metered Outlet 34.6KW 3PH 415V 60A 560P6 42 Outlet

Environmental Conditions
Maximum Operating Temperature	60°C
Interfaces/Ports
Network (RJ-45)	Yes
Management
Management	NMC3 Web SNMP CLI
Remote Outlet Switching	Yes
Power Description
Input Voltage	415 V AC
Power Source	Power Supply
Output Voltage	240 V AC
Input Current	60 A
General Information
Product Type	PDU
Manufacturer Part Number	APDU11450SM
Manufacturer Website Address	http://www.schneider-electric.com.au
Packaged Quantity	1
Manufacturer	Schneider Electric SA
Product Name	NetShelter 42-Outlets PDU
Product Line	NetShelter
Brand Name	APC by Schneider Electric
Technical Information
Plug/Connector Type	IEC 60309 60A 3P+N+PE
Phase	Three Phase
Receptacle Type	IEC 60320 C13/C15

	IEC 60320 C13/C15/C19/C21
Load Capacity (Watt)	43.50 kW
PDU Type	Switched
	Metered-by-Outlet
Receptacle Detail	21 x IEC 60320 C13/C15
	21 x IEC 60320 C13/C15/C19/C21
Physical Characteristics
Weight (Approximate)	12.70 kg
Form Factor	Rack
Mount Type	Rack-mountable
Rack Height	0U
Placement	Side
Cord Length	3 m
Height	1826 mm
Width	55.9 mm
Depth	74.9 mm
Mounting Orientation	Vertical
Mounting Preference	No Preference
Miscellaneous
Application/Usage	Server/Network Rack
	IT Equipment
	Data Center
Mercury Free	Yes
For Country/Region	United States
TAA Compliant	No
Product Take Back Program	No
RoHS Exemption Information	https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=APDU11450SM_ROHS_DECLARATION&p_FileName=APDU11450SMKIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=595098418&lang=en-us
EU RoHS Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=595098418&lang=en-us
REACH free of SVHC	No
WEEE Statement	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
